Cisco RV180 Administration Guide

Configuring the Firewall
Firewall Configuration Examples
Cisco RV180/RV180W Administration Guide 100
4
To e n a b l e S I P A L G :
STEP 1 Choose Firewall > Advanced Settings > SIP ALG.
STEP 2 Check the Enable box to enable SIP ALG support. If disabled, the router will not
allow incoming calls to the UAC (User Agent Client) behind the Cisco RV180/
RV180W.
STEP 3 Click Save.
Firewall Configuration Examples
Example 1: Allow inbound HTTP traffic to the DMZ
In this example, you host a public web server on your local DMZ network. You
want to allow inbound HTTP requests from any outside IP address to the IP
address of your web server at any time of day.
Create an inbound rule as follows:
Parameter Value
Connection Type Inbound
Action Always Allow
Service HTTP
Source IP Any
Send to Local Server (DNAT IP) 192.168.5.2 (web server IP address)
Rule Status Enabled
