Status and Statistics
ACL
43 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
4
• Click Clear Interface Counters to clear the counters of all interfaces.
ACL
When the ACL logging feature is enabled, an informational SYSLOG message is generated
for packets that match ACL rules.
To view the interfaces on which packets forward or rejected based on ACLs:
STEP 1 Click Status and Statistics > ACL.
STEP 2 Select the Refresh Rate (time period in seconds) that passes before the page is refreshed. A
new group of interfaces is created for each time period.
The following information is displayed:
• Global Trapped Packet Counter—Number of packets trapped globally due to lack of
resources.
• Trapped Packets—Port/LAG Based—The interfaces on which packets forwarded or
rejected based on ACL rules.
• Trapped Packets—VLAN Based—The VLANs on which packets forwarded or
rejected based on ACL rules.
STEP 3 To manage statistics counters:
• Click Clear Counters to clear the counters of all interfaces.
TCAM Utilization
TCAM holds the rules produced by applications, such as ACLs (Access Control Lists),
Quality of Service (QoS), while Router TCAM holds the rules for IP Routing and user-created
rules.
Some applications allocate rules upon their initiation. Additionally, processes that initialize
during system boot use some of their rules during the startup process.
To view TCAM utilization, click Status and Statistics > TCAM Utilization.
