SpecificationParameter
100 to 240Input Voltage Range (V rms)
90 to 264Maximum Allowable Input Voltage Range (V rms)
50 to 60Frequency Range (Hz)
47 to 63Maximum Allowable Frequency Range (Hz)
1050Maximum Rated Output (W)
Limited to 800W when operating at low-line input
voltage, 100-127 V
36Maximum Rated Standby Output (W)
230Nominal Input Voltage (V rms)
5.2Nominal Input Current (A rms)
1154Maximum Input at Nominal Input Voltage (W)
1190Maximum Input at Nominal Input Voltage (VA)
90Maximum Rated Efficiency (%)
Minimum rating required to achieve 80PLUS platinum
certification.
0.97Maximum Rated Power Factor
Minimum rating required to achieve 80PLUS platinum
certification.
15Maximum Inrush Current (peak A)
0.2Maximum Inrush Current (ms)
12Maximum Ride-Through Time
Time output voltage remains within regulation limits
at 100% load, during input voltage dropout
Power Cord Specifications
Each power supply in the server has a power cord. Standard power cords or jumper power cords are available
for connection to the appliance. The shorter jumper power cords, for use in racks, are available as an optional
alternative to the standard power cords.
Only the approved power cords or jumper power cords listed below are supported.
Note
Cisco Secure Network Server 3700 Series Appliance Hardware Installation Guide
34
Server Specifications
Power Cord Specifications
