Cisco UCS C200 Server Installation and Service Guide
OL-20732-02
Chapter 3 Maintaining the Server
Installing or Replacing Components
Figure 3-12 Drive Numbering and Physical Orientation, Facing Server Front (Small Form Factor)
Figure 3-13 Removing and Replacing Hard Drives (Small Form Factor)
HDD_01 HDD_02 HDD_03
HDD_04 HDD_05 HDD_06 HDD_07 HDD_08
1 Ejector lever 3 Securing screws (four)
2 Release button
282337
3
3
3
3
1 2
