6 Cisco WAP121 and WAP321 Wireless-N Access Points
Verifying the Hardware Installation
To verify the hardware installation, complete the following tasks:
• Check the cable connections.
• Check the state of the indicator lights.
NOTE If you need help resolving a problem, visit the Cisco Support
Community at www.cisco.com/go/smallbizsupport.
Label Activity Description
Power
Off Power is off
Solid Green Power is on. Normal operation using an
external power adaptor.
Solid Amber Power is on. Normal operation using PoE.
Flashing Booting/Firmware upgrade
WLAN
Off Wireless is disabled, for both 2.4 GHz and
5GHz wireless networks
Solid Green Wireless 2.4 GHz band is enabled.
Solid Amber Wireless 5 GHz band is enabled.
Flashing Transmitting/Receiving Data
Flashing Fast (2x
Flashing rate)
Wi-Fi Protected Setup (WPS) is synchronizing
LAN
Off No Ethernet Link
Solid Green Ethernet link is active.
• FE link is detected for Cisco WAP121
• GE link is detected for Cisco WAP321
Solid Amber Ethernet link is active.
• FE link is detected for Cisco WAP321
Flashing Transmitting/Receiving Data
5

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
