CL-S321 Series Service Manual
- 1 -
INTRODUCTION
This manual describes the disassembly and reassembly procedures of CL-S321 Series.
1. SERVICE PARTS LIST
Remarks: When placing an order for service parts, refer to the Parts Price List published separately. If you need the
Parts Price List, consult the local distributor from whom you purchased this product.
1-1. Parts List
Part Number
Part Name
Description
(1)
PPS00173-00
SA MAIN PCB 1 SP 321
Main board assembly module,USB,RS232,CL-S321/S331
(2)
PPS00174-00
SA MAIN PCB 2 SP 321
Main board assembly module,USB,RS232,LAN,CL-S321/S331
(3)
PPF80007-00
SA MOTOR SP 321
Motor module, CL-S321/S331
(4)
PPK90017-00
SA PLATEN SP 321
Platen module, CL-S321/S331
(5)
PPS00175-00
SA LABEL SENSOR SP 321
Label sensor module,CL-S321/S331
(6)
PPT00011-00
SA FEED SWICH SP 321
Feed switch & LED assembly module,CL-S321/S331
(7)
PPS00176-00
SA RIBBON SENSOR SP 321
Ribbon sensor assembly module,CL-S321/S331
(8)
PPM40002-00
SA RIBBON HOLDER SP 321
Ribbon supply & gear module, CL-S321/S331
(9)
PPM80012-00
SA HEAD 1 SP 300
TPH 203dpi module, CL-S300/S321
(10)
PPM80013-00
SA HEAD 1 SP 331
TPH 300dpi module, CL-S331
(11)
PWT20013-00
UNIT POWER SUPPLY 300
Power supply unit, CL-S300
(12)
PWT20014-00
UNIT POWER SUPPLY 321
Power supply unit, CL-S321/S331
(13)
PYX80027-00
BOX
Individual packing box, CL-S321/S331
(14)
PYY00024-00
CARTON MASTER
Master Carton, CL-S321/S331
(15)
PYY30033-00
PAD U
Top polyfoam, CL-S321/S331
(16)
PYY30034-00
PAD L
Bottom polyfoam, CL-S321/S331
