Clarion CZ100E User Manual

23
English
•Connectingtotheexternalamplier
External ampliers can be connected to the 4 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the accessories
Fuse 15A
ANTENNA
(Black)
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Battery +
Phone Mute
Front left +
Rear left +
ACC +
AMP Remote
Ground
Phone Mute / Brown Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Rear left (+) / Green
Rear left (-) / Green with black stripe
Front right (+) / Grey
Front right (-) / Grey with black stripe
Front left (+) / White
Front left (-) / White with black stripe
Battery 12V(+) / Yellow
Remote On / Blue with white stripe
ACC+ / Red
Ground / Black
Illumination / Orange with white stripe
Illumination
Rear right -
Front right -
Rear left -
Front left -
Front right +
Rear right +
Rear audio output (Right)
Subwoofer output 2
Black
Red
Rear Right / SUB OUT 2
Rear audio output (Left)
Subwoofer output 1
Black
White
Rear Left / SUB OUT 1
Black
Black
Steering wheel
control terminal
SWC
4 Channel Amplifier
Red
White
Right
Left
Front audio
output terminal
Gray
Refer to next page.
A
B
C
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
YellowYellow
RedRed
VW , Audi
For VW and Audi: Change wiring like above.
