Clarion CZ104E User Manual

English
6
CZ104E
5. OPERATIONS
Basic Operations
Note:
• Refer to the diagrams in “3. CONTROLS”
when reading this chapter.
CAUTION
When the unit is turned on, starting and
stopping the engine with its volume
raised to the maximum level may harm
your hearing.
Be careful about adjusting the volume.
Power on / off
Notes:
• Start the engine before using this unit.
• Be careful about using this unit for a long
time without running the engine. If you
drain the car’s battery too far, you may not
be able to start the engine and this can
reduce the service life of the battery.
1. Start the engine. The power button / knob
illumination on the unit will light up.
Engine ON
position
2. Press the [SRC /
] button on the front
panel or the remote control to turn on the
power under standby mode. The unit goes
back to the last status after power on.
3. Press and hold the [SRC / ] button on
the front panel or the remote control to
turn off the power.
Mute
Press the [MUTE] button on the remote
control to mute the volume from the unit.
Note:
Doing the operation above again or adjusting
volume will release muting.
Volume adjustment
Rotate the [VOLUME] knob on the front
panel.
The adjustable range of volume is 0 to 40.
CAUTION
While driving, keep the volume level at
which external sounds can still be heard.
Playing source selection
Press [SRC / ] button on the front panel
or the remote control repeatedly to choose
desired playing source.
Note:
Playing source selection means selecting
which mode, such as DISC mode, RADIO
mode, USB mode and AUX mode.
Display system time
Press the [DISP] button on the front panel
or the remote control to switch the display
information from clock, station information
(radio mode), or track information (CD mode,
USB mode).
RESET
If you have below problems, please press
[RESET] button.
• Unit can not power on
• Nothing happens when buttons are pressed
• Display is not accurate
• By pressing [RESET] button, the memories
are initialized.
RESET
System Setup
SCROLL: ON/OFF
For track information that is longer than the
display panel:
When SCOLL is ON, the LCD will scroll the
ID3 TAG information across the display, e.g.:
TRACK -> FILE -> FOLDER -> TITLE ->
ARTIST -> ALBUM -> TRACK ...
When SCROLL is OFF, the LCD will display
one of the ID3 TAG information, the default
is TRACK, but user can adjust it to other ID3
TAG information by press [DISP] button.
BEEP: ON/OFF
Rotate the [VOLUME] knob to choose button
beep sound ON or OFF.
In any mode, press and hold [DISP] button to
enter system setup. Press [
] or [ ]
button to select options, rotate the [VOLUME]
knob to adjust.
AF: ON/OFF (RADIO mode)
Rotate the [VOLUME] knob to choose AF
ON or OFF.
REG: ON/OFF (RADIO mode)
Rotate the [VOLUME] knob to choose REG
ON or OFF.
DX/LO (RADIO mode)
Rotate the [VOLUME] knob to choose radio
local or distant at RADIO mode.
• LO: Only stations with strong signal can
be received.
• DX: Stations with strong and weak signals
can be received.
AUX SENS (AUX mode)
Rotate the [VOLUME] knob to choose AUX
Input sensitivity LOW, MID or HIGH at AUX
mode.
SCRN SVR: ON/OFF
Rotate the [VOLUME] knob to choose SCRN
SVR (screen saver) ON or OFF.
Press the [
] button to enter sound effect
setting mode. First press shows current EQ.
Rotate the [VOLUME] knob to changes EQ in
this order:
OFF -> POP -> CLASSIC -> ROCK -> JAZZ
-> CUSTOM
Press the [VOLUME] knob to conrm.
Rotate the [VOLUME] knob to changes
CUSTOM, and press the [VOLUME] knob,
then press [
] or [ ] button to select
BAS-G or TRE-G, rotate the [VOLUME] knob to
select a value.
BAS-G / TRE-G: (-7)- (+7)
Audio Setup
Press the [ ] button, then press [ ]
or [
] button to select USER preset
including: BALANCE -> FADER -> LOUD,
rotate the [VOLUME] knob to select a value.
BALANCE: LEFT 1-7->CENTER->RIGHT
1-7
FADER: REAR 1-7->CENTER->FRONT 1-7
LOUD: ON / OFF
