Clarion CZ209 Service Manual

-9-
CZ209/CZ209A
ELECTRICAL PARTS LIST
Main PWB(B1) section
Note)1. Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
2. Some parts depend on each model. The model name is specified in the description.
REF No. PART No. DESCRIPTION REF No. P ART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT2 092-4000-51 ANT-RECEPT C445 172-1041-15 0.1uF C810 043-1804-90 0.1uF
BL1 941-0227-02 FAE391-AC1 C447 043-1614-90 470pF C811 043-1802-90 0.01uF
C118 043-1608-90 0.1uF C449 043-1614-90 470pF C812 043-1606-90 1000pF
C119 043-1608-90 0.1uF C450 043-1614-90 470pF C813 043-1804-90 0.1uF
C120 187-1073-15 6.3V 100uF C451 043-1614-90 470pF C814 043-1607-90 0.01uF
C121 043-1608-90 0.1uF C452 043-1614-90 470pF C815 187-1073-15 6.3V 100uF
C122 187-1073-35 16V 100uF
C453 043-1614-90 470pF
C816 043-1806-90 1uF
C123 043-1608-90 0.1uF
C454 043-1614-90 470pF
C817 043-1606-90 1000pF
C124 187-1073-35 16V 100uF C455 043-1614-90 470pF C818 043-1608-90 0.1uF
C125 043-1608-90 0.1uF C500 187-3363-45 10V 33uF C819 187-1073-15 6.3V 100uF
C126 043-1608-90 0.1uF C501 043-1806-90 1uF C820 043-1608-90 0.1uF
C164 187-1063-35 16V 10uF C502 043-1608-90 0.1uF C821 043-1804-90 0.1uF
C202 043-1727-90 47pF C503 043-1608-90 0.1uF C822 043-1802-90 0.01uF
C203 043-1827-90 0.027uF C504 043-1806-90 1uF C824 043-1804-90 0.1uF
C204 043-1827-90 0.027uF C505 043-1804-90 0.1uF C825 043-1824-90 0.22uF
C209 187-1073-25 10V 100uF C506 043-6200-90 10uF C826 043-1625-90 0.022uF
C210 187-1073-25 10V 100uF C507 165-1063-35 16V 10uF C827 043-1608-90 0.1uF
C211 043-1804-90 0.1uF C508 043-1710-90 9pF C828 187-1073-15 6.3V 100uF
C212 043-1804-90 0.1uF C509 043-1710-90 9pF C829 043-1608-90 0.1uF
C213 187-1073-25 10V 100uF C510 043-1719-90 22pF C830 043-1804-90 0.1uF
C214 043-1804-90 0.1uF C511 043-1719-90 22pF C831 187-1073-15 6.3V 100uF
C217 043-1607-90 0.01uF C512 043-1607-90 0.01uF C833 189-3373-11 6.3V 330uF
C218 043-1601-90 100pF C513 043-1601-90 100pF C834 189-4773-22 10V 470uF
C222 043-1719-90 22pF C514 042-1577-00 6.3V 100uF C835 043-1804-90 0.1uF
C224 187-1073-25 10V 100uF C515 043-1607-90 0.01uF C836 165-4753-55 35V 4.7uF
C227 043-1804-90 0.1uF C516 189-1083-12 6.3V 1000uF C837 165-4753-55 35V 4.7uF
C229 043-1607-90 0.01uF C517 043-1607-90 0.01uF C838 043-1800-90 1000pF
C230 043-1607-90 0.01uF C518 043-1802-90 0.01uF C839 043-1800-90 1000pF
C241 042-9102-01 50V 3.3uF LZ C519 043-1617-90 6800pF C840 043-1800-90 1000pF
C250 187-4763-35 16V 47uF C520 043-1802-90 0.01uF C841 043-1800-90 1000pF
C307 187-1053-65 50V 1uF C521 043-1607-90 0.01uF C842 043-1731-90 68pF
C308 187-1053-65 50V 1uF C522 043-1607-90 0.01uF C843 043-1731-90 68pF
C309 187-1053-65 50V 1uF C523 043-1601-90 100pF C844 043-1608-90 0.1uF
C310 187-1053-65 50V 1uF C599 043-1802-90 0.01uF C845 043-1608-90 0.1uF
C311 187-1053-65 50V 1uF C600 043-1804-90 0.1uF C846 043-1608-90 0.1uF
C312 187-1053-65 50V 1uF C601 043-1609-90 1500pF C847 187-1053-65 50V 1uF
C313 187-4763-15 6.3V 47uF C602 043-1715-90 15pF C848 187-1073-15 6.3V 100uF
C314 187-1063-35 16V 10uF C603 043-1715-90 15pF C849 043-1804-90 0.1uF
C315 043-1735-90 100pF C604 043-1706-90 5pF C850 043-1804-90 0.1uF
C316 043-1735-90 100pF C605 043-1706-90 5pF C853 189-4773-22 10V 470uF
C317 043-1804-90 0.1uF C606 043-1609-90 1500pF C854 043-1841-90 0.047uF
C318 187-4763-35 16V 47uF C607 043-1804-90 0.1uF C855 043-1608-90 0.1uF
C319 043-1735-90 100pF C608 187-1073-15 6.3V 100uF C856 043-1804-90 0.1uF
C320 043-1735-90 100pF C609 043-1804-90 0.1uF C857 187-1073-15 6.3V 100uF
C321 187-1063-35 16V 10uF C610 043-1608-90 0.1uF C858 043-1804-90 0.1uF
C322 187-1063-35 16V 10uF C611 043-1806-90 1uF C859 187-1073-15 6.3V 100uF
C323 187-1063-35 16V 10uF C612 043-1608-90 0.1uF C860 187-1073-15 6.3V 100uF
C324 187-1063-35 16V 10uF C613 043-1608-90 0.1uF C861 043-1608-90 0.1uF
C325 043-1802-90 0.01uF C614 043-1607-90 0.01uF C870 187-1073-35 16V 100uF
C337 187-1063-35 16V 10uF C620 187-2253-65 50V 2.2uF C903 043-1804-90 0.1uF
C338 187-1063-35 16V 10uF C621 187-4753-65 50V 4.7uF D100 001-0592-61 1N5404
C339 187-1063-35 16V 10uF C623 187-2253-65 50V 2.2uF D109 001-0466-61 1A4
C340 187-1063-35 16V 10uF C624 189-4773-22 10V 470uF D110 001-0466-61 1A4
C346 043-1841-90 0.047uF C633 187-4763-15 6.3V 47uF D163 001-0504-32 HZS6 A3L
C401 042-4416-00 3000uF C800 187-1073-15 6.3V 100uF D302 001-4316-17 LM3Z4V3T1G
C413 178-4742-78 0.47uF C801 043-1620-90 4700pF D401 001-4316-24 LM3Z8V2T1G
C414 178-4742-78 0.47uF C802 043-1802-90 0.01uF D402 001-1323-90 L1SS355T1G
C415 178-4742-78 0.47uF C803 043-1804-90 0.1uF D403 001-1323-90 L1SS355T1G
C416 178-4742-78 0.47uF C804 043-1804-90 0.1uF D500 001-1323-90 L1SS355T1G
C421 043-1620-90 4700pF C805 187-3363-25 6.3V 33uF D502 001-4301-26 HZU4.7B2
C428 187-1063-35 16V 10uF C806 043-1804-90 0.1uF D503 001-1323-90 L1SS355T1G
C435 178-4742-78 0.47uF C807 187-1073-15 6.3V 100uF D504 001-1323-90 L1SS355T1G
C442 187-1053-65 50V 1uF C809 043-1804-90 0.1uF D505 001-1323-90 L1SS355T1G
