Clarion PP-2449V-C User Manual

- 7 -
PP-2449V-B
PP-2449V-C
ELECTRICAL PARTS LIST
Main PWB(B1) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
C546 178-8222-78 8200pF(V-C)
C547 178-4732-78 0.047uF(V-B)
C547 178-3332-78 0.033uF(V-C)
C548 178-4732-78 0.047uF(V-B)
C548 178-3332-78 0.033uF(V-C)
C549 178-2232-78 0.022uF(V-B)
C549 178-4732-78 0.047uF(V-C)
C550 178-2232-78 0.022uF(V-B)
C550 178-4732-78 0.047uF(V-C)
C551 178-1832-78 0.018uF(V-B)
C551 178-2232-78 0.022uF(V-C)
C552 178-1832-78 0.018uF(V-B)
C552 178-2232-78 0.022uF(V-C)
C553 178-5632-78 0.056uF(V-B)
C553 178-6832-78 0.068uF(V-C)
C554 178-5632-78 0.056uF(V-B)
C554 178-6832-78 0.068uF(V-C)
C555 178-5632-78 0.056uF(V-B)
C555 178-4732-78 0.047uF(V-C)
C556 178-5632-78 0.056uF(V-B)
C556 178-4732-78 0.047uF(V-C)
C557 178-5632-78 0.056uF(V-B)
C557 178-6832-78 0.068uF(V-C)
C558 178-5632-78 0.056uF(V-B)
C558 178-4732-78 0.047uF(V-C)
C559 166-2201-50 22pF CH
C560 166-2201-50 22pF CH
C561 166-2201-50 22pF CH
C562 166-2201-50 22pF CH
C563 178-5632-78 0.056uF(V-B)
C563 178-6832-78 0.068uF(V-C)
C564 178-5632-78 0.056uF(V-B)
C564 178-4732-78 0.047uF(V-C)
C568 178-3932-78 0.039uF
C569 178-3932-78 0.039uF
C570 178-3932-78 0.039uF
C571 178-3932-78 0.039uF
C572 168-1022-55 1000pF
C573 182-1053-69 50V1uF
C574 182-2253-69 50V2.2uF
C576 168-1045-56 0.1uF
C701 172-1041-15 0.1uF
C702 042-0447-00 16V2200uF
C703 168-2222-55 2200pF
C704 168-2222-55 2200pF
C705 168-2222-55 2200pF
C706 168-2222-55 2200pF
C707 168-2222-55 2200pF
C708 168-2222-55 2200pF
C709 168-2222-55 2200pF
C710 168-2222-55 2200pF
C711 168-2222-55 2200pF
C712 172-1041-15 0.1uF
C713 182-1063-39 16V10uF
C714 183-6843-69 50V0.68uF
C802 182-4763-39 16V47uF
C803 182-1063-39 16V10uF
C804 182-4763-19 6.3V47uF
C805 182-4763-19 6.3V47uF
C806 182-1063-39 16V10uF
C807 182-1063-39 16V10uF
C808 168-1045-56 0.1uF
C809 184-4773-39 16V470uF
C810 183-4756-58 35V4.7uF NP
C811 168-1045-56 0.1uF
C812 168-1045-56 0.1uF
C813 172-4741-15 0.47uF
C901 178-2242-78 0.22uF
C338 168-3312-55 330pF
C339 168-3312-55 330pF
C340 182-1063-39 16V10uF
C341 182-1063-39 16V10uF
C342 168-3332-78 0.033uF
C343 182-1063-39 16V10uF
C344 182-1063-39 16V10uF
C345 182-1063-39 16V10uF
C346 182-1063-39 16V10uF
C501 168-5612-55 560pF(V-B)
C503 168-5612-55 560pF(V-B)
C505 166-2201-50 22pF CH
C506 166-2201-50 22pF CH
C507 168-8212-55 820pF(V-B)
C508 166-2201-50 22pF CH
C509 166-2201-50 22pF CH
C510 168-2222-55 2200pF(V-B)
C511 168-2222-55 2200pF(V-B)
C512 166-2201-50 22pF CH
C513 166-2201-50 22pF CH
C514 168-8212-55 820pF(V-B)
C515 166-2201-50 22pF CH
C516 166-2201-50 22pF CH
C517 178-6832-78 0.068uF(V-B)
C517 178-3332-78 0.033uF(V-C)
C518 178-2242-78 0.22uF(V-B)
C518 043-0309-92 10V 0.68uF(V-C)
C519 043-0309-91 10V 0.82uF(V-B)
C519 178-4732-78 0.047uF(V-C)
C520 178-2742-78 0.27uF(V-B)
C520 178-1042-78 0.1uF(V-C)
C521 166-2201-50 22pF CH
C522 166-2201-50 22pF CH
C523 166-2201-50 22pF CH
C524 166-2201-50 22pF CH
C525 043-0309-91 10V 0.82uF(V-B)
C525 178-4732-78 0.047uF(V-C)
C526 178-2742-78 0.27uF(V-B)
C526 178-1042-78 0.1uF(V-C)
C527 178-6832-78 0.068uF(V-B)
C527 178-3332-78 0.033uF(V-C)
C528 178-2242-78 0.22uF(V-B)
C528 043-0309-92 10V 0.68uF(V-C)
C529 178-5632-78 0.056uF(V-B)
C529 178-1842-78 0.18uF(V-C)
C530 178-5632-78 0.056uF(V-B)
C531 178-1242-78 0.12uF(V-B)
C531 178-1842-78 0.18uF(V-C)
C532 178-1242-78 0.12uF(V-B)
C532 178-1842-78 0.18uF(V-C)
C533 178-1842-78 0.18uF(V-B)
C533 178-8232-78 0.082uF(V-C)
C534 178-1842-78 0.18uF(V-B)
C535 178-6832-78 0.068uF(V-B)
C535 178-1242-78 0.12uF(V-C)
C536 178-6832-78 0.068uF(V-B)
C536 178-1242-78 0.12uF(V-C)
C537 166-2201-50 22pF CH
C538 166-2201-50 22pF CH
C539 166-2201-50 22pF CH
C540 166-2201-50 22pF CH
C541 166-2201-50 22pF CH
C542 166-2201-50 22pF CH
C543 166-2201-50 22pF CH
C544 166-2201-50 22pF CH
C545 178-1832-78 0.018uF(V-B)
C545 178-8222-78 8200pF(V-C)
C546 178-1832-78 0.018uF(V-B)
BL101 880-1917U AM/FM TUNER(V-B)
BL101 880-1917R AM/FM TUNER(V-C)
C101 168-1032-55 0.01uF(V-B)
C102 182-1053-69 50V1uF(V-B)
C103 166-4701-50 47pF CH(V-B)
C104 166-4701-50 47pF CH(V-B)
C105 166-1511-50 150pF CH(V-B)
C105 119-0000-05 1/10W 0 ohm JW
(V-C)
C106 168-3332-78 0.033uF(V-B)
C107 168-6812-55 680pF(V-B)
C108 168-4732-78 0.047uF(V-B)
C109 168-3922-55 3900pF(V-B)
C110 168-1022-55 1000pF(V-B)
C111 168-1032-55 0.01uF(V-B)
C112 168-1032-55 0.01uF(V-B)
C113 166-2201-50 22pF CH(V-B)
C114 166-1007-50 10pF CH
C116 168-1045-56 0.1uF
C117 178-2232-78 0.022uF
C118 168-1022-55 1000pF
C119 182-1073-29 10V100uF
C120 042-0458-93 50V2.2uF
C122 182-1073-29 10V100uF
C123 182-1073-29 10V100uF
C125 182-4763-39 16V47uF
C126 183-1056-68 50V1uF NP
C127 168-1532-55 0.015uF
C128 168-3332-78 0.033uF
C129 168-3332-78 0.033uF
C150 166-1201-50 12pF CH
C203 166-1011-50 100pF CH
C204 166-1011-50 100pF CH
C205 166-1011-50 100pF CH
C206 166-1011-50 100pF CH
C207 168-1045-56 0.1uF
C208 168-1045-56 0.1uF
C212 166-8097-50 8pF CH
C213 182-4763-19 6.3V47uF
C214 168-1045-56 0.1uF
C215 182-4763-19 6.3V47uF
C301 168-4722-55 4700pF
C303 184-2273-28 10V220uF
C306 184-1083-29 10V1000uF
C307 182-1063-39 16V10uF
C311 183-1063-37 16V10uF
C312 183-1063-37 16V10uF
C313 183-1063-37 16V10uF
C314 183-1063-37 16V10uF
C315 182-2263-19 6.3V22uF
C316 182-1053-69 50V1uF
C318 183-1043-69 50V0.1uF
C319 183-1043-69 50V0.1uF
C321 182-1053-69 50V1uF
C322 178-1042-78 0.1uF
C323 178-1042-78 0.1uF
C325 182-1053-69 50V1uF
C326 182-1053-69 50V1uF
C328 182-1063-39 16V10uF
C329 182-1063-39 16V10uF
C330 182-1063-39 16V10uF
C331 182-1063-39 16V10uF
C332 182-1053-69 50V1uF
C333 182-1053-69 50V1uF
C334 178-1242-78 0.12uF
C335 178-1242-78 0.12uF
C336 168-1532-55 0.015uF
C337 168-1532-55 0.015uF
Note)Some parts depend on each model.The model name is specified in the description.
(V-B):PP-2449V-B (V-C):PP-2449V-C
