Clarion PP-3000M-A User Manual

PN-3000P
PP-3000M
- 10 -
ELECTRICAL PARTS LIST
Switch PWB(B1) section
ANT902 060-8062-50 CERAMIC-ANT
C802 168-1042-78 16V 0.1uF
C803 168-1042-78 16V 0.1uF
C804 168-4732-78 0.047uF K
C805 168-4732-78 0.047uF K
C806 168-4732-78 0.047uF K
C807 166-2211-50 220pF CH
C901 168-1042-78 16V 0.1uF
C902 166-1011-50 100pF CH
C903 168-1042-78 16V 0.1uF
C904 166-1011-50 100pF CH
C905 166-1011-50 100pF CH
C906 042-0423-97 16V 10uF
C907 168-1042-78 16V 0.1uF
C908 168-1042-78 16V 0.1uF
C909 178-3312-78 330pF
CCT801 050-0145-52 1/16W 1k ohm x4
D801 001-0529-32 MA8056-M
D802 001-0529-32 MA8056-M
D803 001-0529-32 MA8056-M
D804 001-0529-32 MA8056-M
D805 001-0529-32 MA8056-M
D806 001-7093-91 RFY1112H-16-TR
YEL
D807 001-7093-91 RFY1112H-16-TR
YEL
D808 001-7093-91 RFY1112H-16-TR
YEL
D809 001-7093-91 RFY1112H-16-TR
YEL
D810 001-7093-91 RFY1112H-16-TR
YEL
D811 001-7093-91 RFY1112H-16-TR
YEL
D812 001-7093-91 RFY1112H-16-TR
YEL
D813 001-7093-91 RFY1112H-16-TR
YEL
D814 001-7093-91 RFY1112H-16-TR
YEL
D815 001-7093-91 RFY1112H-16-TR
YEL
D816 001-7093-91 RFY1112H-16-TR
YEL
D817 001-7093-91 RFY1112H-16-TR
YEL
D818 001-7093-91 RFY1112H-16-TR
YEL
D819 001-7093-91 RFY1112H-16-TR
YEL
D820 001-7093-91 RFY1112H-16-TR
YEL
D821 001-7093-91 RFY1112H-16-TR
YEL
D822 001-7093-91 RFY1112H-16-TR
YEL
D823 001-7093-91 RFY1112H-16-TR
YEL
D824 001-7093-91 RFY1112H-16-TR
YEL
D830 001-7093-91 RFY1112H-16-TR
YEL
D831 001-7093-91 RFY1112H-16-TR
YEL
D832 001-7093-91 RFY1112H-16-TR
YEL
D833 001-7093-91 RFY1112H-16-TR
YEL
D834 001-7093-91 RFY1112H-16-TR
YEL
D835 001-7093-91 RFY1112H-16-TR
YEL
D836 001-7093-91 RFY1112H-16-TR
YEL
D837 001-7093-91 RFY1112H-16-TR
YEL
D838 001-7093-91 RFY1112H-16-TR
YEL
D839 001-7093-91 RFY1112H-16-TR
YEL
D846 001-7093-91 RFY1112H-16-TR
YEL
D847 001-7093-91 RFY1112H-16-TR
YEL
D848 001-7093-91 RFY1112H-16-TR
YEL
D849 001-7093-91 RFY1112H-16-TR
YEL
D850 001-7093-91 RFY1112H-16-TR
YEL
D851 001-7093-91 RFY1112H-16-TR
YEL
D852 001-7093-91 RFY1112H-16-TR
YEL
D853 001-7093-91 RFY1112H-16-TR
YEL
D855 001-7093-91 RFY1112H-16-TR
YEL
D856 001-7093-91 RFY1112H-16-TR
YEL
D857 001-7093-91 RFY1112H-16-TR
YEL
D858 001-7093-91 RFY1112H-16-TR
YEL
D859 001-7093-91 RFY1112H-16-TR
YEL
D860 001-7093-91 RFY1112H-16-TR
YEL
D861 001-7093-91 RFY1112H-16-TR
YEL
D862 001-7093-91 RFY1112H-16-TR
YEL
D864 001-7093-91 RFY1112H-16-TR
YEL
D865 001-7093-91 RFY1112H-16-TR
YEL
D866 001-7093-91 RFY1112H-16-TR
YEL
D867 001-7093-91 RFY1112H-16-TR
YEL
D869 001-7093-91 RFY1112H-16-TR
YEL
D870 001-7093-91 RFY1112H-16-TR
YEL
IC801 051-6075-00 LC75816W-8722-E
IC901 060-8079-90 UGZZ5-601D
J801 074-3013-72 22P
J901 074-3013-66 16P
LCD801 379-1392-50 INDICATOR (LCD)
L901 010-3104-54 600 ohm/100MHz
L902 010-3104-54 600 ohm/100MHz
L903 010-3104-54 600 ohm/100MHz
L904 010-3104-54 600 ohm/100MHz
L906 010-3104-54 600 ohm/100MHz
L907 010-3104-54 600 ohm/100MHz
L909 010-3104-54 600 ohm/100MHz
L910 010-3104-54 600 ohm/100MHz
L911 010-3104-54 600 ohm/100MHz
L912 010-3104-54 600 ohm/100MHz
R801 119-0000-05 1/10W 0 ohm JW
R802 119-3331-15 1/10W 33k ohm
R803 119-1021-15 1/10W 1k ohm
R804 116-3321-15 1/4W 3.3k ohm
R805 116-3321-15 1/4W 3.3k ohm
R806 116-3321-15 1/4W 3.3k ohm
R807 116-3321-15 1/4W 3.3k ohm
R808 116-3321-15 1/4W 3.3k ohm
R809 116-3921-15 1/4W 3.9k ohm
R810 116-2421-15 1/4W 2.4k ohm
R811 116-4721-15 1/4W 4.7k ohm
R812 116-4721-15 1/4W 4.7k ohm
R813 116-4721-15 1/4W 4.7k ohm
R814 116-4721-15 1/4W 4.7k ohm
R815 116-2221-15 1/4W 2.2k ohm
R816 116-2221-15 1/4W 2.2k ohm
R817 119-1521-15 1/10W 1.5k ohm
R819 116-3321-15 1/4W 3.3k ohm
R822 119-2421-15 1/10W 2.4k ohm
R823 116-4721-15 1/4W 4.7k ohm
R824 119-2421-15 1/10W 2.4k ohm
R825 116-4721-15 1/4W 4.7k ohm
R826 119-2421-15 1/10W 2.4k ohm
R827 116-3921-15 1/4W 3.9k ohm
R828 119-2421-15 1/10W 2.4k ohm
R829 116-2421-15 1/4W 2.4k ohm
R830 119-2421-15 1/10W 2.4k ohm
R831 116-4721-15 1/4W 4.7k ohm
R832 119-2421-15 1/10W 2.4k ohm
R833 119-1521-15 1/10W 1.5k ohm
R905 119-2711-15 1/10W 270 ohm
R909 119-1031-15 1/10W 10k ohm
R914 119-5631-15 1/10W 56k ohm
R916 119-1821-15 1/10W 1.8k ohm
R917 119-2711-15 1/10W 270 ohm
R918 119-1011-15 1/10W 100 ohm
R919 119-1011-15 1/10W 100 ohm
S801 016-7004-00 ROTARY SWITCH
S802 013-6201-52 SKPMAP010
S803 013-6202-52 SKPMBJE010
S804 013-6202-52 SKPMBJE010
S807 013-6202-52 SKPMBJE010
S808 013-6201-52 SKPMAP010
S809 013-6201-52 SKPMAP010
S810 013-6202-52 SKPMBJE010
S811 013-6202-52 SKPMBJE010
S812 013-6202-52 SKPMBJE010
S813 013-6201-52 SKPMAP010
S814 013-6201-52 SKPMAP010
S815 013-6202-52 SKPMBJE010
S816 013-6202-52 SKPMBJE010
S818 013-6201-52 SKPMAP010
S819 013-6201-52 SKPMAP010
S820 013-6201-52 SKPMAP010
S821 013-6202-52 SKPMBJE010
S822 013-6201-52 SKPMAP010
S823 013-6201-52 SKPMAP010
S824 013-6201-52 SKPMAP010
S825 013-6201-52 SKPMAP010
S826 013-6201-52 SKPMAP010
S827 013-6201-52 SKPMAP010
S828 013-6201-52 SKPMAP010
TM901 073-0778-90 TERMINAL
TM902 073-0778-90 TERMINAL
TM903 073-0778-90 TERMINAL
TM904 073-0778-90 TERMINAL
PWB 039-2925-01 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
