Clarion PP-3000M-A User Manual

PN-3000P
PP-3000M
- 11 -
Note) Some parts depend on each model. The model name is specified in the description.
Main PWB(B2) section
ANT101 092-2210-00 ANTENNA RECEPT
BL101 880-2091M FM/AM TUNER
C104 168-2222-55 2200pF K
(PN-3000P)
C108 119-0000-05 1/10W 0 ohm JW
C109 166-2201-50 22pF CH
C110 168-1042-78 16V 0.1uF
C111 178-3342-78 0.33uF
C112 163-4763-15 6.3V 47uF
C113 178-1052-78 1uF
C114 178-1052-78 1uF
C115 119-0000-05 1/10W 0 ohm JW
C116 168-1222-55 1200pF K
C117 178-1052-78 1uF
C118 168-4732-78 0.047uF K
C119 168-1022-55 1000pF K
C120 168-4722-55 4700pF K
C121 168-4722-55 4700pF K
C122 163-1073-35 16V 100uF
C123 168-2222-55 2200pF K
C124 168-1022-55 1000pF K
C125 168-2232-55 0.022uF K
C126 168-2232-55 0.022uF K
C127 168-1022-55 1000pF K
C128 168-1022-55 1000pF K
C129 178-1052-78 1uF
C130 168-1022-55 1000pF K
C131 163-1073-35 16V 100uF
C132 166-2201-50 22pF CH
C133 166-2201-50 22pF CH
C134 166-2201-50 22pF CH
C135 166-2201-50 22pF CH
C136 178-1052-78 1uF
C137 178-1052-78 1uF
C138 178-3342-78 0.33uF
C140 163-1063-35 16V 10uF
C141 163-1063-35 16V 10uF
(PN-3000P)
C142 168-1042-78 16V 0.1uF
C143 166-6801-50 68pF CH
C144 043-0548-50 2.2uF
C201 043-0548-50 2.2uF
C202 043-0548-50 2.2uF
C203 043-0548-50 2.2uF
C204 043-0548-50 2.2uF
C220 163-2273-25 10V 220uF
C227 042-0643-58 6.3V 330uF
C228 163-2273-25 10V 220uF
C229 163-1063-35 16V 10uF
C230 168-1042-78 16V 0.1uF
C232 163-1063-35 16V 10uF
C233 168-1042-78 16V 0.1uF
C236 178-1052-78 1uF
C238 178-3342-78 0.33uF
C241 168-1022-55 1000pF K
C242 168-1022-55 1000pF K
C301 163-4753-65 50V 4.7uF
C302 168-1042-78 16V 0.1uF
C303 166-1811-50 180pF CH
C304 166-1007-50 10pF CH
C306 168-1042-78 16V 0.1uF
C307 168-1042-78 16V 0.1uF
C308 166-8097-50 8pF C CH
C309 166-8097-50 8pF C CH
C310 168-1022-55 1000pF K
C311 163-4753-65 50V 4.7uF
C312 168-1042-78 16V 0.1uF
C313 163-4753-65 50V 4.7uF
C314 168-1042-78 16V 0.1uF
C315 168-1022-55 1000pF K
C316 168-1022-55 1000pF K
C317 166-1011-50 100pF CH
C318 168-1042-78 16V 0.1uF
C319 168-5622-55 5600pF K
C320 168-5622-55 5600pF K
C323 168-1022-55 1000pF K
C324 163-2273-05 4V 220uF
C325 168-2222-55 2200pF K
C326 166-4711-50 470pF CH
C327 163-2263-35 16V 22uF
C328 168-1022-55 1000pF K
C329 166-1007-50 10pF CH
C330 163-1063-35 16V 10uF
C331 166-1011-50 100pF CH
C333 168-1042-78 16V 0.1uF
C334 163-4763-15 6.3V 47uF
C335 178-1052-78 1uF
C336 168-3332-78 0.033uF K
C338 168-1022-55 1000pF K
C339 168-1022-55 1000pF K
C340 166-1007-50 10pF CH
C341 168-4712-55 470pF K
C342 168-1042-78 16V 0.1uF
C343 168-1022-55 1000pF K
C345 168-3322-55 3300pF K
C346 168-3322-55 3300pF K
C347 168-3322-55 3300pF K
C348 168-3322-55 3300pF K
C350 042-0643-58 6.3V 330uF
C351 168-4722-55 4700pF K
C352 168-2222-55 2200pF K
C353 168-2222-55 2200pF K
C354 168-2222-55 2200pF K
C355 168-2222-55 2200pF K
C356 163-1073-15 6.3V 100uF
C359 168-1022-55 1000pF K
C360 166-4711-50 470pF CH
C361 043-0554-90 25V 10uF
C401 168-1042-78 16V 0.1uF
C402 168-1042-78 16V 0.1uF
C404 166-5096-50 5pF CH
C406 166-5096-50 5pF CH
C407 168-1042-78 16V 0.1uF
C408 163-4763-15 6.3V 47uF
C409 168-1042-78 16V 0.1uF
C412 168-1032-55 0.01uF K
C413 163-1073-35 16V 100uF
C425 168-1042-78 16V 0.1uF
C501 168-1042-78 16V 0.1uF
C502 168-1042-78 16V 0.1uF
C503 168-1042-78 16V 0.1uF
C504 168-1042-78 16V 0.1uF
C505 166-5611-50 560pF CH
C506 166-5611-50 560pF CH
C507 166-5611-50 560pF CH
C508 166-5611-50 560pF CH
C509 166-2201-50 22pF CH
C510 166-2201-50 22pF CH
C511 043-0554-90 25V 10uF
C512 178-3342-78 0.33uF
C513 166-2201-50 22pF CH
C514 166-2201-50 22pF CH
C516 166-5611-50 560pF CH
C517 166-5611-50 560pF CH
C519 166-5611-50 560pF CH
C520 166-5611-50 560pF CH
C521 168-1042-78 16V 0.1uF
C522 178-3342-78 0.33uF
C523 163-1063-35 16V 10uF
C525 163-1073-35 16V 100uF
C530 163-1073-35 16V 100uF
C532 168-1042-78 16V 0.1uF
C533 168-5632-78 16V 0.056uF
C534 168-5632-78 16V 0.056uF
C535 168-5632-78 16V 0.056uF
C536 168-5632-78 16V 0.056uF
C537 178-1052-78 1uF
C540 163-1063-35 16V 10uF
C541 168-1522-55 1500pF K
C546 168-1042-78 16V 0.1uF
C547 178-1052-78 1uF
C549 163-2273-25 10V 220uF
C550 178-4742-78 0.47uF
C551 168-1042-38 50V 0.1uF
C552 163-4763-35 16V 47uF
C553 163-4763-35 16V 47uF
C554 189-3383-31 16V 3300uF
C556 172-1041-15 0.1uF
C557 163-4763-35 16V 47uF
C559 168-6822-55 6800pF K
C560 168-6822-55 6800pF K
C561 168-6822-55 6800pF K
C562 168-6822-55 6800pF K
C563 168-6822-55 6800pF K
C564 166-2201-50 22pF CH
C565 168-6822-55 6800pF K
C566 168-6822-55 6800pF K
C567 043-0604-90 25V 10uF B
C568 168-6822-55 6800pF K
C569 168-6822-55 6800pF K
C571 043-0566-90 50V 2.2uF K
C572 178-1052-78 1uF
C573 168-1042-78 16V 0.1uF
C574 163-1063-35 16V 10uF
C575 168-2232-55 0.022uF K
C576 163-1073-35 16V 100uF
C577 168-2212-55 220pF K
C578 119-0000-05 1/10W 0 ohm JW
CCT401 050-0145-52 1/16W 1k ohm x4
CCT402 050-0145-52 1/16W 1k ohm x4
CCT403 050-0145-52 1/16W 1k ohm x4
CCT404 050-0145-52 1/16W 1k ohm x4
D106 001-0580-90 1SS352
D108 001-0529-48 MA8091-H
D109 001-0580-90 1SS352
(PN-3000P)
D208 001-0580-90 1SS352
D210 001-0529-72 MA8200-M
D211 001-9210-50 AVR-
M1608C270MTAAD
D212 001-9210-50 AVR-
M1608C270MTAAD
D213 001-9210-50 AVR-
M1608C270MTAAD
D214 001-9210-50 AVR-
M1608C270MTAAD
D215 001-2412-90 RR264M-400
D401 001-0580-90 1SS352
D505 001-0529-48 MA8091-H
D506 001-2640-90 D1FJ4
D508 001-0529-48 MA8091-H
D510 001-2015-00 RL253
D511 001-0580-90 1SS352
D512 001-0529-48 MA8091-H
D514 001-0580-90 1SS352
D515 001-0529-34 MA8062-L
D516 001-0580-90 1SS352
D567 001-0580-90 1SS352
D568 001-0580-90 1SS352
D569 001-4301-68 HZU18B1
D570 001-4301-68 HZU18B1
D571 001-4301-68 HZU18B1
IC101 051-6524-90 AK2301A-E1
IC103 051-3034-90 NJM4558V
IC104 051-3519-90 NJU7771F05-TE2
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
