929-0390-81
- M7 -
to A7
D2
D1
to C2
to A1
D3
to D2
to
D1
A3
A5
A6
A2
A1
A4
A7
to D3
C1
to A4
to A5
C4
C3
to A3
C2
to A2
to A6
to C1
to C4
to C3
to B1
to B2
B1
B2
1
*24
13
20
*28
23
21
*28
*25
14
11
15
37
36
*32
*30
*31
27
22
27
8
26
18
3
4
17
26
*29
27
*29
5
2
19
6
33
34
35
7
23
16
23
12
10
33
34
27
27
9
27
27
to E1
E1
EXPLODED VIEW/PARTS LIST
Main section
1 HBS-585-200 LOWER UNIT ASSY 1
2 966-0667-21 DISC STP-ASSY L 1
3 HBS-584-100 DH-SEL-ASSY S 1
4 HBS-583-100 DH-SEL-ASSY R 1
5 966-0670-22 DS-SP-ASSY L 1
6 966-0671-23 DS-SP-ASSY R 1
7 966-0672-21 REAR-P-ASSY 1
8 966-1871-20 N-DRIVE-CH UNIT 1
9 966-1764-21 UPPRR UNIT ASSY 1
10 HBS-566-300 DISCHOLDER UNIT 1
11 966-1771-21 SLIDE-P-ASSY F 1
12 966-0709-21 SLIDE-P-ASSY R 1
13 HBS-605-100 CD-PWB-ASSY 1
14 620-1640-20 SW-H-PLATE 1
15 620-1778-20 GAP PLATE F 1
16 620-1662-21 GAP PLATE R 1
17 620-1685-21 DS-PLATE L 1
18 620-1686-20 DS-PLATE R 1
19 621-1634-23 DISC STOPPER R 1
* Do not reuse the following parts.
(No.24,25,28,29,30,31,32)
20 621-1636-24 SW LINK 1
21 621-1765-20 UD-GEAR-D 1
22 621-1715-20 FPC-STOPPER 1
23 716-1850-01 SCREW (M2.0x2.0) 4
24 716-3629-00 SCREW (M2.0x2.5) 1
25 716-1851-02 SCREW (M2.0x3.0) 1
26 716-3450-00 SCREW (M1.7x2.0) 2
27 716-3451-01 SCREW (M1.7x2.5) 8
28 746-0761-00 WASHER 2
29 744-0045-01 C-RING 2
30 347-7271-00 FPC SHEET 1
31 347-7275-00 PROTECT SHEET 1
32 347-7276-00 FPC-SHEET C 1
33 800-4921-60 VINYL-COAT WIRE 1
34 802-4921-60 VINYL-COAT WIRE 1
35 345-5824-00 RUBBER PART 1
36 621-1763-20 LOADING GUIDE B 1
37 716-1859-01 SCREW (M1.7x2.0) 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
To Next Page
