SPEAKER WIRING DIAGRAMS
XC7420 - Two 4 Ohm Speakers - 4 Ohm Stereo
XC7420 - Four 4 Ohm Speakers - 2 Ohm Stereo
BRIDGED
4
CH2
CH1
BRIDGED
4
CH2
CH1
