Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
Processor Options
Intel® Core™ i7 Processor
i7-7500U (2.70GHz)
4MB Smart Cache, 14nm, DDR4-2133MHz, TDP 15W
Intel® Core™ i5 Processor
i5-7200U (2.50GHz)
3MB Smart Cache, 14nm, DDR4-2133MHz, TDP 15W
Intel® Core™ i3 Processor
i3-7100U (2.40GHz)
3MB Smart Cache, 14nm, DDR4-2133MHz, TDP 15W
BIOS
64Mb SPI Flash ROM
AMI BIOS
Memory
Two 260 Pin SO-DIMM Sockets Supporting DDR4 2133 MHz
Memory
Memory Expandable up to 32GB
(The real memory operating frequency depends on the FSB
of the processor.)
LCD Options
14" (35.56cm), 16:9, HD (1366x768) (Thickness: 3.6mm)/
F
HD (1920x1080) (Thickness: 3.0mm)
Video Adapter
Intel GPU (CPU integrated)
Intel HD Graphics 620
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Storage
One Changeable 2.5" 7mm (h) SATA HDD/SSD
(Factory Option) One M.2 SATA/PCIe Gen3 x4 Solid State
Drive (SSD)
Pointing Device
Built-in Touchpad
Keyboard
“WinKey” keyboard (with embedded numeric keypad)
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
(Factory Option) Built-In Array Microphone
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel PTT for Systems Without TPM Hardware
(Factory Option) TPM 2.0
M.2 Slots
Slot 1 for WLAN and Bluetooth Combo Module
Slot 2 for SATA/PCIe Gen3 x4 SSD
(Factory Option) Slot 3 for 3G/4G Module
To Next Page
