Clevo N240BU User Manual

Disassembly
2 - 14 Removing and Installing the M.2 SSD Module
2.Disassembly
Removing and Installing the M.2 SSD Module
m.2 SSD Removal Procedure
1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 6).
2. The M.2 SSD module will be visible at point on the mainboard (Figure 8a).
3. Remove the screw
(Figure 8b)
4. The M.2 SSD module (Figure 8c) will pop-up, and you can remove it from the computer.
1
2
3
b.
c.
a.
2
3
1
3

3.M2 SATA-1 Module
•1 Screw
Figure 8
M.2 SSD Module
Removal
a. Locate the M.2 SSD.
b. Remove the screw.
c. The M.2 SSD module
will pop up.
