Introduction
1 - 10 Mainboard Overview - Top (Connectors)
1.Introduction
Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. DC-In Jack
2. Mini Display Port
3. HDMI Port
4. Keyboard Cable
Connector
5. LED KB
Connector
6. MicroSD Card
Reader
7. Thunderbolt 4
Port
8. RJ-45 LAN Jack
7
8
6
5
1 3
4
2
