Clevo P770DM User Manual

Disassembly
2 - 10 Removing the M.2 SSD Module
2.Disassembly
Removing the M.2 SSD Module
Note that the SSD (if installed) is beside the HDD bay.
1. Turn off the computer, and turn it over, remove the battery (page 2 - 5).
2. Remove the screw from the SSD (Figure 6a
).
3. The M.2 SSD module will pop-up (Figure 6b
).
4. Lift the M.2 SSD module up and off the computer (Figure 6c
).
5. Reverse the process to install a new SSD (make sure that the hexagonal screw
is in the correct location
depending upon the size of the module).

2. M.2 SSD Module
•1 Screw
Figure 6
M.2 SSD Module
Removal
a. Remove the screws.
b. The module will pop up.
c. Lift the module out.
1
6
2
6
2
3
a. b.
2
1
2
c.
3
3
