Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
Processor Options
Intel® Pentium™ Processor
N3520 (2.17GHz)
2MB L3 Cache, 22nm, DDR3L-1333MHz, TDP 7.5W
Intel® Celeron™ Processor
N2920 (1.86GHz)
2MB L3 Cache, 22nm, DDR3L-1066MHz, TDP 7.5W
N2820 (2.13GHz), N2815 (1.86GHz)
1MB L3 Cache, 22nm, DDR3L-1066MHz, TDP 7.5W
N2806 (1.60GHz)
1MB L3 Cache, 22nm, DDR3L-1066MHz, TDP 4.3W
BIOS
64Mb SPI Flash ROM
AMI BIOS
Storage
(Factory Option) One Changeable 9.5mm(h) Super Multi
Optical Device Drive
(Factory Option) Dummy ODD
One Changeable 2.5" 7.0mm (h) SATA HDD/SSD
Memory
For N3520, N2920, N2820 & N2815 Processors:
Two 204 Pin SO-DIMM Sockets Supporting DDR3L 1066/
1333MHz Memory
Memory Expandable up to 8GB
(The real memory operating frequency depends on the FSB
of the processor.)
For N2806 Processor
One 204 Pin SO-DIMM Socket Supporting DDR3L 1066MHz
Memory
Memory Expandable up to 8GB
(The real memory operating frequency depends on the FSB
of the processor.)
LCD
15.6" (39.62cm) HD (Thickness: 3.8mm)
Video Adapter
Intel HD Graphics
Dynamic Frequency (Intel Dynamic Video Memory Technol-
ogy for up to 1.7GB)
Microsoft DirectX® 11 Compatible
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Security
Security (Kensington® Type) Lock Slot
BIOS Password
(Factory Option) TPM v1.2
Keyboard
Full-size “WinKey” keyboard (with numeric keypad)
Pointing Device
Built-in Touchpad
Interface
One USB 3.0 Port
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
Three USB 2.0 Ports
