Cointra CADI Series User Manual

EN
56
cod. 3542C090 - Rev. 01 - 09/2022
CADI
This symbol means “Caution,” and is displayed next to safety war-
nings. Carefully observe such warnings to avoid hazardous situa-
tions, property damage, and injury to people and animals.
Important information involving no risk of injury or property damage is indicated by this symbol.
The CE marking certies that products meet the fundamental requirements of the applicable
European directives. The declaration of conformity can be requested from the manufacturer.
The unit is suitable for operation in a partially protected with temperatures from -5°C to +60°C.
product. Such representations may in-
clude slight, insignicant differences
with respect to the product supplied.
• APPLIANCE INTENDED FOR DOME-
STIC USE; NOT VALID FOR INDU-
STRIAL USE.
1 USER'S MANUAL ................................................. 57
1.1 Introduction ........................................................ 57
1.2 Control panel ...................................................... 57
1.3 Turning the heater on and off .............................. 57
1.4 Settings ............................................................... 58
1.5 Faults .................................................................. 58
2 INSTALLATION MANUAL..................................... 59
2.1 General information ............................................ 59
2.2 Location .............................................................. 59
2.3 Assembling the heater ........................................ 60
2.4 Hydraulic connections ......................................... 61
2.5 Gas connection ................................................... 62
2.6 Air and flue gas ducts ......................................... 62
3 SERVICE AND MAINTENANCE ........................... 63
3.1 Adjustments ........................................................ 63
3.2 Commissioning ................................................... 64
3.3 Maintenance ....................................................... 64
3.4 Replacing the batteries ....................................... 65
4 TECHNICAL DATA AND CHARACTERISTICS .... 66
4.1 Dimensions and connections .............................. 66
4.2 Overview and main components ........................ 67
4.3 Hydraulic circuit .................................................. 68
4.4 Technical data table ............................................ 69
4.5 Wiring diagram .................................................... 71
