Setpoints
Password
EnterPassword
Password is a four-digit number. Password enables change of relevant protected set points Use ↑ or
↓ keys to set and ENTER key to enter the password.
ChangePassword
Use ↑ or ↓ keys to set and ENTER key to change the password.
Hint:
At first the Password has to be entered before the new Password can be changed.
Basic settings
Gen-set name
User defined name, used for InteliLite identification at remote phone or mobile connection.
Gen-set name is max 14 characters long and have to be entered using LiteEdit software.
Nomin power [kW]
Nominal power of the generator
Step: 1kW
Range: 1 – 4000 kW
Nominal current [ A ]
It is current limit for generator *IDMT over current and short current protection and means maximal
continuous generator current. See Generator protections: *2Inom del, Ishort setpoints.
Nominal current can be different from generator rated current value.
Step: 1 A
Range: 1 - 5000 A
CT Ratio [/5A]
Gen-set phases current transformers ratio.
Step: 1 A
Range: 1 – 5000 A / 5A
*PT ratio [/1]
Gen-set potential transformers ratio.
Step: 0,1 V / V
Range: 0,1 – 500,0 V / V
Nomin voltage [V]
Nominal generator voltage (phase to neutral)
Step: 1V
Range: 100 – 300 V
Nominal freq [Hz]
Nominal generator frequency (usually 50 or 60 Hz )
Step: 1Hz
Range: 45 – 65 Hz
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 28
IL-MRS-2.2.pdf
