1
1. Display Screen
2. Control Knob
3. Voltage Selection
4. TF Slot and USB Port
5. Nozzle Kit
6. Platform
7. Base Frame
8. Z Gantry Frame
9. Y Stepper
10. Y Limit Switch
11. Z Stepper
12. Z Limit Switch
13. X Stepper
14. Spool Holder
15. Control Box
16. Nozzle Assembly Connection
17. Hot Bed Connection
18. Power Cable Connection
19. Extruder (E) Stepper
20. X Limit Switch
1. Introduction
1
2
14
17
19
20
15
16
18
9 10 11 12 134
3
5 6 7 8
