3
Install the Gantry Frame
Insert the Teflon pipe into
the quick connector
*CR-10 mini without T-Bracket (right).
M5X25
4pcs
Note: Make sure that the nut
for profile has been turned by
90° before fastening the
T-shaped fixing block.
3.Device Installtion 01
Install the T-shaped fixing block.
