Crestron CP3 & CP3N 3-Series Control Systems
Operations Guide – DOC. 7316C 3-Series Control Systems: CP3 & CP3N • 21
Configure for Operations
Before setting up the CP3 the time and time zone needs to be set. The CP3 can also
be further configured using a Web browser.
Set Date & Time
1. Establish communication with the CP3 as described in “Establishing
Communication” on page 18.
2. In Crestron Toolbox, select Functions | System Clock….
3. Set the date and time.
Online Configuration
The CP3 can be configured using the built-in Web based setup tool.
1. Using Internet Explorer, navigate to http://xxx.xx.xx.xxx/setup where
xxx.xx.xx.xxx is the IP address of the control system.
NOTE: The Web-based setup tool is only accessible from Internet
Explorer.
NOTE: If a security warning is displayed, click Install to continue.
The control system’s “Welcome” screen is displayed.
“Welcome” Screen
2. Click Setup to display the “CP3 Setup” menu.

Crestron CP3 Specifications

General

Motherboard chipset	-
Processor frequency	- GHz
Storage media	Flash
Card reader integrated	Yes
Total storage capacity	4 GB
Compatible memory cards	MMC
Internal memory	0.5 GB
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Serial interface type	RS-232/422/485
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	5 - 45 °C
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
