Observe the LED Indicators
Refer to the following table for information about the LED indicators on
the device.
LED Indicator Color Meaning
PWR White Device is powered on with audio
passing.
Red Device is in standby mode.
Off Device is not powered on.
LAN White The device is powered on and has a
valid IP address.
Off Device is not connected to a network
or the IP address is invalid.
NAX White AoIP is ready to pass and the unit's
PTP clock is synced.
Off No AoIP is passing to or from the unit
and/or PTP is not synced.
SOURCE 1-8 White Signal is detected on the specified
input/source.
Red There is clipping on an analog input or
bitstream audio detected on a digital
input.
Off There is no signal detected on the
specified input/source.
ZONE 1-4 White There is audio output on the indicated
zone.
Red Clipping is detected on the output
audio.
LED Indicator Color Meaning
SETUP Solid Red
The SETUP button is pressed.
Blinking Red
A network reset or factory restore has
been initiated via the adjacent SETUP
button.
Reset the Device
A network reset or factory restore may be performed when
troubleshooting.
Network Reset
1. Ensure the device is powered on.
2. Press and hold the SETUP button for up to 15 seconds until the
SETUP LED flashes red.
The device will reboot, and the default network settings will be reset,
such as default Hostname, DHCP enabled, no static IP.
Factory Restore
1. Turn off the device by disconnecting the power cable from the device.
2. Press and hold the SETUP button and then reconnect the power
cable while still holding the SETUP button. Continue holding the
SETUP button for up to 30 seconds until the SETUP LED flashes.
The device will reboot, and all the factory default settings will be
restored, such as Zone settings, names, multicast addressing, etc.
CAUTION: Performing a factory restore will clear all settings from
the device configuration.
6
DM-NAX-4ZSP
QuickStart
DM NAX™ 4-Zone Streaming Preamplifier
