Cub Cadet 2146 Parts Manual

-19-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 ME-ZX390/11317D Engine, Complete 1
2 ME-110-3892 Pin, Hollow Dowel 2
3 ME-191-2107 Starter 1
4 ME-853-0016 Washer, ET Lock, 5/16 1
5 ME-526-0115 Washer, Flat, 5/16 1
6 ME-860-2008 Nut, Hex, M8 x 1.25 1
7 ME-510-0162 Bearing, Camshaft 1
8 ME- 509-0258 Seal, Crankshaft Oil 1
9 ME-510-0160 Bearing, Crankshaft 1
10 ME-510-0163 Bearing, Balancer Shaft 2
11 ME-775-0074 Pin, Alignment 2
12 ME-505-0180 Plug, 1/4 NPT Countersunk Hd 2
13 ME-823-0003-07 Screw, Pan Head, M6 x 1 x 30 2
14 ME-166-0832 Coil, Ignition 1
15 ME-166-0837 Spacer, Ignition Coil, M6 x 30 2
16 ME-718-1040 Screw, Hex Hd, M8 x 1.25 x 40 2
17 751-3132 Pipe, Oil Drain 1
18 751-3129 Cap, Oil Drain 1
19 ME-102-1441 Gasket Set, Engine 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
CYLINDER BLOCK
Engine
Gasket
Set
19
