Appendix A System Data
Table 14. CSM Series Water Softeners - Flow Rate Data (GPM)
Model Service Suggested
Progressive
Flow Trip
Point* (gpm)
Drain
Minimum Continuous Peak Backwash*
(Cycle 1)
Brine Draw
Slow Rinse
(Cycle 2)
Fast Rinse
(Start during
Cycle 3)
150-2 4.4 67 94 65 10 2.4 10
210-2 6.2 76 102 75 13.5 3.5 13.5
300-2 9.8 84 112 80 20 5.0 20
300-3 9.8 152 210 150 20 5.0 20
450-2 9.8 79 106 75 20 5.0 20
450-3 9.8 135 192 130 20 5.0 20
600-2 14.2 94 125 90 30 7.0 30
600-3 14.2 183 252 180 30 7.0 30
750-2 19.2 97 129 95 45 10.0 45
750-3 19.2 201 267 200 45 10.0 45
900-2 19.2 96 127 95 45 10.0 45
900-3 19.2 193 259 190 45 10.0 45
*The suggested Progressive Flow Trip Point is simply a suggested flow rate at which point an additional tank will be
brought on-line if facility flow demands meet this rate. The Culligan MVP Controller will not remove tank brought on-line
by attaining the Trip Point unless the flow is <95% of the Trip Point amount for a 60 second period. In the event additional
units are not brought on-line or off-line when desired, simply adjust the programmed Trip Point. Refer to the system in-
struction manual operation and programming sections for more information about the progressive flow mode of operation.
