D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
When the WPS function is enabled, the Information section is available on the page.
Parameter Description
WPS state
The state of the WPS function:
• Configured (all needed settings are specified; these settings
will be used upon establishing the wireless connection)
• Unconfigured (after activating the WPS function, the SSID
and the encryption key will be configured automatically, the
network authentication type will be changed to WPA2-PSK).
Default PIN code
The PIN code of the extender. This parameter is used when
connecting the extender to a registrar to set the parameters of the
WPS function.
Network name (SSID) The name of the extender's wireless network.
Network Authentication
The network authentication type specified for the wireless network.
Encryption The encryption type specified for the wireless network.
Password PSK
The encryption password specified for the wireless network.
UPDATE Click the button to update the data on the page.
RESET TO
UNCONFIGURED
Click the button to reset the parameters of the WPS function.
Page 59 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
