D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the Wireless Networks section, the list of available wireless networks is displayed. To view
the latest data on available wireless networks, click the Update list button.
To connect to a wireless network from the list, select the needed network. Move the Network
options switch to the right to view more detailed information on the network to which the
extender connects. If a password is required, enter it in the relevant field. Click the CONNECT
button.
To connect to a hidden network, select the Connect to hidden network value from the
Connecting to network drop-down list. Enter the name of the network in the Network name
(SSID) field. If needed, fill in the BSSID field. Then select the needed type of authentication from
the Network authentication drop-down list.
When the Open, WEP-64, or WEP-128 authentication type is selected, the following settings are
displayed on the page:
Parameter Description
Enable encryption WEP
For Open authentication type only.
To activate WEP encryption, move the switch to the right. Upon that
the WEP type and Default key ID drop-down lists, the
Encryption key WEP as HEX switch, and four Encryption key
fields are displayed on the page.
WEP type
For Open authentication type only.
WEP encryption type with a 64-bit or 128-bit key.
Select the WEP-64 value to specify keys containing 5 ASCII
symbols or 10 HEX symbols.
Select the WEP-128 value to specify keys containing 13 ASCII
symbols or 26 HEX symbols.
Default key ID
The number of the key (from first to fourth) which will be used for
WEP encryption.
Encryption key WEP as
HEX
Move the switch to the right to set a hexadecimal number as a key
for encryption.
Encryption key
(1-4)
Keys for WEP encryption. The extender uses the key selected from
the Default key ID drop-down list. It is required to specify all the
fields.
Page 66 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
