D-Link DAP-1530 User Manual

24D-Link DAP-1530 User Manual
Section 3 - Conguration
Conguration
Home
The home screen gives a summary of the current status of devices connected to the DAP-1530. A green check between the device
and the uplink router indicates that there is an active connection. A red cross indicates that there is no connection present, or there
is a connection error. If there’s no active uplink connection, click on the Click to Repair button to start the setup wizard.
Note: If the DAP-1530 is connected to a Wi-Fi Mesh supported router, then the home screen will only show the Firmware Upgrade
function. Other functions for the DAP-1530 can be congured from the router’s conguration page. For more details, refer to “Home
- Connected to a Wi-Fi Mesh Router” on page 27.
Uplink Router This icon shows the status of the Internet connection to the uplink router. It is grey if the DAP-1530 is not connected
to an uplink router. Once connected, click on it to see its connection details.
DAP-1530 Click on this icon to see details of the uplink network the DAP-1530 is connected to or connect to another uplink router.
Connected Clients Click on the Connected Clients icon to see client details.

D-Link DAP-1530 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Antenna type	External
Antennas quantity	2
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3ab
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
Internal memory	64 MB
Certification	FCC, CE, IC, UL
Product color	Grey, White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	48.7 mm
Width	50.7 mm
Height	97.9 mm
Weight	116 g
