D-Link DAP-1530 User Manual

4D-Link DAP-1530 User Manual
Section 1 - Product Overview
What is a Wireless Extender?
The DAP-1530 acts as a repeater to extend the range of an existing wireless network to provide a better signal for parts of your
home or oce that may have poor or no reception. Your existing wireless signal will be re-broadcast by the DAP-1530, allowing
you to reach the farthest corners of your home or oce. The extended network can simply use the same network credentials as the
existing network, or you can specify a dierent network name and password, giving you the exibility to control network access.
You may also use the DAP-1530 as a wireless access point by connecting an Ethernet cable.
Extend Your Wireless Network using Wi-Fi
Router
Internet
DAP-1530
Extender
Wireless Devices
Computer
Create a Wireless Network using Ethernet
Router
Internet
DAP-1530
Extender
Wireless Devices
Computer

D-Link DAP-1530 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Antenna type	External
Antennas quantity	2
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3ab
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
Internal memory	64 MB
Certification	FCC, CE, IC, UL
Product color	Grey, White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	48.7 mm
Width	50.7 mm
Height	97.9 mm
Weight	116 g
