D-Link DAP-1530 User Manual

33D-Link DAP-1530 User Manual
Section 3 - Conguration
IPv6 - Autoconguration (SLAAC/DHCPv6)
My Internet Connection
is
Select Autoconfiguration (SLAAC/DHCPv6) to have the
DAP-1530 automatically receive an IPv6 address from the
uplink router.
Obtain a DNS server
address automatically
You can select to obtain IPv6 DNS server information
automatically, or you can select to congure DNS servers
manually by selecting next to the option Use the following
DNS address.
Primary DNS Server For manual settings, enter the primary IPv6 DNS server address.
Secondary DNS Server For manual settings, enter the secondary IPv6 DNS server
address. This is optional but will provide backup if the primary
server fails.
IPv6 - Static IPv6
My Internet Connection
is
Select Static IPv6 to manually assign an IP address to the
DAP-1530.
IPv6 Address Enter the IPv6 address that you want to assign to the extended
network AP. This address should be outside of the uplink
router’s DHCP address pool.
Subnet Prex Length Enter the length of the IPv6 subnet prex.
Default Gateway Enter the default gateway.
Primary DNS Server Enter the primary IPv6 DNS server address.
Secondary DNS Server Enter the secondary IPv6 DNS server address. This is optional
but will provide backup if the primary server fails.
IPv6 - Local Connectivity Only
My Internet Connection
is
Select Local Connectivity Only to set an IPv6 address only
for the local network.
LAN IPv6 Link-Local
Address
The link-local address of the DAP-1530.

D-Link DAP-1530 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Antenna type	External
Antennas quantity	2
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3ab
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
Internal memory	64 MB
Certification	FCC, CE, IC, UL
Product color	Grey, White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	48.7 mm
Width	50.7 mm
Height	97.9 mm
Weight	116 g
