55D-Link DAP-1650 User Manual
Section 3 - Conguration
Wi-Fi Protected Setup
This section allows you to congure how the DAP-1650 uses Wi-Fi Protected Setup (WPS) to create a secure wireless connection.
Enable:
Lock WPS-PIN
Setup:
Current PIN:
Check the box to enable WPS.
Check the box to disable WPS using the PIN method. If this
option is selected, wireless clients will only be able to use the
WPS-PBC (push-button connection) method.
Displays the current PIN which can be used by wireless clients
to connect to the access point. Click Reset PIN to Default to
return the PIN to its factory default. Click Generate New PIN
to randomly generate a new PIN.
Click Add Wireless Device With WPS to activate the WPS-PBC
(push-button) method. You will then have 120 seconds to press
the WPS button on the new device that you wish to connect.
Click Save Settings at the bottom of the page to save the
current conguration.
