D-Link DES-1008D Quick Installation Guide

3
100Mbps speed or light amber for hookup
to 10Mbps speed.
2. The ‘‘Full-Duplex/Collision” LED indicator
depends upon LAN card capabilities for full
duplex or half duplex.
Step 4 –Hub to DES-1008D
A hub (10 or 100BASE-TX) can be connected to the
DES-1008D via a two-pair Category 3, 4, 5
UTP/STP straight cables. For 100Mbps operation
a Category 5 cable must be used. The connection is
accomplished from any port of the hub to any port
of the switch
Step 5 – DES-1008D to switch
The DES-1008D can be connected to another switch or
other devices (routers, bridges, etc.) via a two-pair Cate-
gory 3, 4, 5 UTP/STP straight or crossover cable. A
Category 5 cable must be used for 100Mbps operation.
The connection can be done from any (MDI-X) port of the
Switch (Switch A) to any of the 10Mbps, 100Mbps (MDI-
X) port of the other switch (switch B) or other devices
Additional Information
If you are encountering problems setting up your
network, please refer to the User’s Guide that
came with the switch. It contains many more rules,
charts, explanations and examples to help you get
your network up and running.
Additional help is available online at
http://www.dlink.com in the United States, at
http://www.dlink.co.uk in the United Kingdom, or
through our offices listed at the back of the User’s
Guide.

D-Link DES-1008D Specifications

General

Switch type	Unmanaged
Switch layer	-
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Full duplex	Yes
Networking standards	IEEE 802.3, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
MAC address table	1024 entries
Product color	Black
Maximum data transfer rate	100 Mbit/s
Mean time between failures (MTBF)	116186 h
Input current	1 A
Output voltage	5 V
Package depth	158 mm
Package width	104 mm
Package height	94 mm
Package weight	310 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1885 mm
Pallet gross weight (air)	330500 g
Quantity per pallet (air)	1000 pc(s)
Shipping (inner) case width	211 mm
Shipping (inner) case height	350 mm
Shipping (inner) case length	543 mm
Shipping (inner) case weight	6230 g
Shipping (inner) case net weight	3960 g
Number of cartons per pallet (air)	50 pc(s)
Quantity per shipping (inner) case	20 pc(s)
Harmonized System (HS) code	85176990
