D-Link DES-105 User Manual

ii
ABLE OF ONTENTST C
ABOUT T
IN
UNPAC
ID
CONNECTING THE SWITCH........................................................9
C
MOUNTING THE SWITCH ON A WALL...................................11
TECHNICAL SPECIFICATIONS .................................................13
RJ-45 PIN SPECIFICATION .........................................................15
HIS GUIDE .......................................................................1
PURPOSE.............................................................................................1
TRODUCTION ..............................................................................2
FAST ETHERNET TECHNOLOGY .........................................................2
SWITCHING TECHNOLOGY .................................................................2
802.1P AND QOS ................................................................................3
FEATURES ..........................................................................................4
KING AND SETUP..............................................................6
UNPACKING........................................................................................6
SETUP.................................................................................................6
ENTIFYING EXTERNAL COMPONENTS ..............................7
FRONT PANEL ....................................................................................7
REAR PANEL ......................................................................................8
ONNECTING THE SWITCH........................................................9
PC TO DES-105/108...........................................................................9
HUB TO DES-105/108........................................................................9
DES-105/108 TO OTHER DEVICES......................................................9
PORT SPEED & DUPLEX MODE ........................................................10

D-Link DES-105 Specifications

General

MAC address table	2000 entries
Jumbo frames support	Yes
Packet buffer memory	0.384 MB
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Dimensions (WxDxH)	100 x 98 x 28 mm
Connectivity technology	Wired
Switch type	Unmanaged
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	5
Certification	RoHS, FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB
Product color	Black
Rack mounting	No
LED indicators	Link, Power, Y
Housing material	Metal
Input current	1 A
Input voltage	5 V
Power consumption (typical)	3.10 W
Mean time between failures (MTBF)	495709 h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	98 mm
Width	100 mm
Height	28 mm
Weight	265 g
