D-Link DES-105 User Manual

3
multiple segments is one of the most common ways of increasing available
bandwidth. If segmented correctly, most network traffic will remain within
a single segment, enjoying the full-line speed bandwidth of that segment.
Switches provide full-line speed and dedicated bandwidth for all
connections. This is in contrast to hubs, which use the traditional shared
networking topology, where the connected nodes contend for the same
network bandwidth. When two switching nodes are communicating, they
are connected with a dedicated channel between them, so there is no
contention for network bandwidth with other nodes.
For Ethernet networks, a switch is an effective way of eliminating the
problem of chaining hubs beyond the “two-repeater limit.” A switch can
be used to split parts of the network into different collision domains,
making it possible to expand your Ethernet network beyond the 205-meter
network diameter limit for 100BASE-TX networks. Switches supporting
both 10Mbps Ethernet and 100Mbps Fast Ethernet are also ideal for
bridging between existing 10Mbps networks and newer 100Mbps
networks.
Switching LAN technology is a marked improvement over the previous
generation of network hubs and bridges, which were characterized by
higher latencies. Routers have also been used to segment local area
networks, but the cost of a router, the setup and maintenance required,
make routers relatively impractical. Today switches are an ideal solution
to most kinds of local area network congestion problems.
802.1p and QoS
The DES-105/108 Switch supports 802.1p priority queuing Quality of
Service and both models provide 2 priority queues for users to prioritize
traffic.

D-Link DES-105 Specifications

General

MAC address table	2000 entries
Jumbo frames support	Yes
Packet buffer memory	0.384 MB
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Dimensions (WxDxH)	100 x 98 x 28 mm
Connectivity technology	Wired
Switch type	Unmanaged
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	5
Certification	RoHS, FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB
Product color	Black
Rack mounting	No
LED indicators	Link, Power, Y
Housing material	Metal
Input current	1 A
Input voltage	5 V
Power consumption (typical)	3.10 W
Mean time between failures (MTBF)	495709 h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	98 mm
Width	100 mm
Height	28 mm
Weight	265 g
