D-Link DSL-2640B User Manual

Web Configuration
D-Link DSL-2640B User Manual 109
Status
Summary Information of the Router
Choose Status > Device Info, the right page appears.
LAN IPv4 Address: The management IPv4 address.
Default Gateway: In the bridging mode there is no gateway. In other modes,
it is the address of the uplink equipment, for example, PPPoE/PPPoA.
DNS Server: In the PPPoE/PPPoA mode, it is obtained from the uplink
equipment. In the bridging mode, there is no DNS Server address and you
can manually enter the information.
LAN IPv6 Address: The management IPv6 address.
Default IPv6 Gateway: No gateway in a pure bridging mode; under other
modes such as PPPoE/PPPoA, it is the address of the uplink equipment
(support IPv6).
DHCP Client
Click DHCP Clients and the right page appears. You can query the IP address
assignment for MAC address at the LAN side of the DSL router and obtain the IP
Address from the DHCP server through Ethernet and wireless in the DSL router.

D-Link DSL-2640B Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz -60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b transfer rates	11, 5.5, 2, and 1 Mbps
IEEE 802.11g transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector
LAN interface	four RJ-45 ports
Ethernet connection type	10/100BASE-T
