D-Link DWA-172 User Manual

19D-Link DWA-172 User Manual
Section 3 - Conguration
Using Windows
®
7
Windows
®
7 users may use the built-in wireless utility. If you are using another company’s utility, please refer to the user manual
of your wireless adapter for help with connecting to a wireless network. Most utilities will have a “site survey” option similar to
the Windows
®
7 utility as seen below.
Left-click the wireless icon in your system tray (lower-right corner
next to the time).
If you receive the Wireless Networks Detected bubble, click on the
center of the bubble to access the utility.
or
The utility will display any available wireless networks in your area.
Click on a network (displayed using the SSID) and click the Connect
button.
If you get a good signal but cannot access the Internet, check your
TCP/IP settings for your wireless adapter. Refer to the Networking
Basics section in this manual for more information.

D-Link DWA-172 Specifications

General

Interface	WLAN
USB ports quantity	1
Connectivity technology	Wireless
Chipset	-
Internal	No
Certification	FCC Class B\\r IC\\r CE\\r C-Tick\\r Wi-Fi Certified\\r Wi-Fi Protected Setup
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency range	2.4 - 5 GHz
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	433 Mbit/s
WLAN data transfer rates supported	1, 2, 5.5, 11, 12, 24, 36, 48, 54, 150, 433 Mbit/s
Gain	3 dBi
Storage temperature (T-T)	-20 - 75 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	208 mm
Package width	137 mm
Package height	36 mm
Package weight	60 g
Output voltage	5 V
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	2100 mm
Pallet gross weight (air)	191200 g
Quantity per pallet (air)	960 pc(s)
Harmonized System (HS) code	85176990
Shipping (inner) case width	443 mm
Shipping (inner) case height	320 mm
Shipping (inner) case length	457 mm
Shipping (inner) case weight	7300 g
Shipping (inner) case net weight	6300 g
Number of cartons per pallet (air)	24 pc(s)
Quantity per shipping (inner) case	40 pc(s)

Weight and Dimensions

Depth	15 mm
Width	15.7 mm
Height	193 mm
Weight	23.2 g
