D-Link DWL-3200AP - AirPremier - Wireless Access Point User Manual

93
DWL-3200AP User’s Manual
D-Link Systems, Inc.
 In this window, enter the Computer name.
 Select Workgroup and enter the name of the Workgroup.
 All computers on your network must have the same Workgroup name.
 Click OK.
Networking Basics
The wireless adapter-equipped computers in your network must be in the same IP
Address range (see Getting Started in this manual for a definition of IP Address Range.)
To check on the IP Address of the adapter, please do the following:
 Right-click on the Local Area Connection icon in the task bar.
 Click on Status.
Checking the IP Address in Windows
®
XP

D-Link DWL-3200AP - AirPremier - Wireless Access Point Specifications

General

Device Type	Wireless Access Point
Form Factor	External
Frequency Band	2.4 GHz, 5 GHz
Data Transfer Rate	54 Mbps
Ethernet Ports	1 x 10/100Base-TX
Antenna Type	Detachable
Power over Ethernet (PoE)	Yes
Compliant Standards	IEEE 802.3af
Operating Temperature	0 °C to 40 °C
Storage Temperature	-20 °C to 70 °C
Wireless Standard	IEEE 802.11b, IEEE 802.11g
Security	WPA, WPA2, WEP, 802.1x
Features	QoS
Humidity	10% to 90% non-condensing
Power Supply	External power adapter
