D-Link DWR-M960 User Manual

User Manual of DWR-M960
-59-
Figure 5-2-19 Wi-Fi security
Object
Description
Wireless ACL Mode
If you choose 'Allowed Listed', only those clients whose wireless
MAC addresses are in the access control list will be able to
connect to your Access Point. When 'Deny Listed' is selected,
these wireless clients on the list will not be able to connect the
Access Point.
MAC Address
The MAC address of the client.
Comment
Comment
5.2.4.4. Site Survey
This page provides tool to scan the wireless network. If any Access Point or IBSS is found, you could choose to connect
it manually when client mode is enabled.
Figure 5-2-20 Site Survey
5.2.4.5. WPS

D-Link DWR-M960 Specifications

General

Frequency Bands	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
SIM Card Slot	Yes
Antenna Type	External
Wireless Speed	Up to 300 Mbps
Cellular Connectivity	4G LTE
USB Port	1 x USB 2.0
Weight	500 g
Wireless Standard	802.11b/g/n
Security	WPA/WPA2
