D-Link DWR-M960 User Manual

User Manual of DWR-M960
-66-
Figure 5-2-27 PPTP
Object
Description
Server
Type the name of PPTP Server.
Username
Enter the user name provided by your ISP.
Password
Enter the password provided by your ISP.
MTU
You can keep the maximum transmission unit (MTU) as default.
5.2.6.2. L2TPv2
This page is used to configure the parameters for Internet network which connects to the L2TPv2 server.
Figure 5-2-28 LT2P
Object
Description
Server
Type the name of L2TP Server.
Username
Enter the user name provided by your ISP.
Password
Enter the password provided by your ISP.
MTU
You can keep the maximum transmission unit (MTU) as default.

D-Link DWR-M960 Specifications

General

Frequency Bands	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
SIM Card Slot	Yes
Antenna Type	External
Wireless Speed	Up to 300 Mbps
Cellular Connectivity	4G LTE
USB Port	1 x USB 2.0
Weight	500 g
Wireless Standard	802.11b/g/n
Security	WPA/WPA2
