Cassette loading inoperative.
Is Motor 12V
IN05 pin ⑦ and ⑨ supplied ?
Check I805
Check connector PAN04 pin
⑦, ⑥, ⑤ and ④
and CAM SW and
DECK Mechanism
Is 5V supplied at pin
of IN01?
Check pattern.
Check pattern.
Check DN13, RCN22, RN21
Check IN01
Are there changes in the cam
data when the cassette is in ?
Is 6V applied to pin ④ of IN05
when casette IN ?
Is 5V applied to pin ⑥ of IN05
when cassette IN ?
Is 6.2V applied to pin ⑩ of IN05
when cassette IN ?
Check connector PAN04 pin
① and ② and loading motor
in DECK Mechanism.
No
YES
YES
YES
YES
YES
YES
YES
No
No
H.
