94
Power supply is normal
No video
Check clock, enable and
data of tuner
Check pin 35, 36, 37
of I701
Check
oscillation
at pin 24 of I701
Check Tuner
Is IF signal from tuner normal ?
Refer from EE mode
no video trouble shooting
flow chart
B.
Yes
Yes
No
No
No
96
98
Table of Contents
Default Chapter
2
Table of Contents
2
Specifications
4
Satety Checking after Servicing
5
Insulation Resistance Test
5
Dielectric Strength Test
5
Clearance Distance
5
Leakage Current Test
5
Important Service Notes
6
X-RAY Radiation Precaution
6
Safety Precaution
6
Product Safety Notice
6
Service Notes
6
General Adjustment
7
General
7
Vertical Height Adjustment
7
Focus Adjustment
7
RF AGC Adjustment
7
High Voltage Check
7
X-RADIATION Protection Circuit Test
7
White Valance Adjustment
7
Convergence Magnet Assembly Positioning
8
Leadless(Chip) Instruction
10
Cleaning and Rubrication of Deck Mecanism
10
Leadless(Chip) Component Removal Instruction
10
Leadless(Chip) Component Identification
11
Mechanical Disassembly(DECK)
12
Top View
12
Bottom View
13
F/L Mechanism View
14
General Removal View
15
Mechanical Checks/Gear Alignment
20
Mechanical Adjustments
25
Shape & Equipment of DVN-14/20F6N
27
Dvn-14F6N/Dvn-20F6N
27
Panel View
29
Remote Controller
30
Electrical Adjustments
32
Servo
32
Audio
34
Video
36
Signal Flow
38
Video & Audio
38
Troubleshooting According to
87
Power Supply Unit
87
Vertical, Horizontal Unit
89
Servo/Syscon Unit
91
Video Unit
96
Audio Unit
100
Electrical Parts List
103
Standard Part Number Coding
103
