Door Switch
When the door spin o is opened during spin drying the lever of the door switch which sites a top the door spin o falls off
the contact, and cuts off the power going into the spin motor.
Brake System
When the door spin is opened, the link brake and brake wire is loosened.
And then the brake band touches the drum coupling assembly and stops the spin dryer as it is pulled by the spring in
the brake fix plate assembly.
Brake Band Gap Control
The band brake works best when the gap between it and the drum coupling is about 2mm when the door spin is
closed. The spin dryer stops slowly if the gap is too large.
SPIN BELLOWS ASS'Y
The wrinkled rubber device below the spindryer is called
spin bellows assembly.
It has a waterseal and an oilless metal inside to prevent
leakage and so that spin dryer may work smoothly.
