1.FREEZER & REFRIGERATOR DOORS
1) Insert flat type(-) screw driver between Hinge
cover and Cabinet surface to remove the Cover
(Be careful not to break the hooks of Cover and
not to damage the Cabinet surface.)
2) Remove 4 bolts with 10mm wrench.
3) Disconnect Connector Housing
4) Lift F-Door a little to remove it.
5) Unfasten Hinge Pin with 6mm wrench.
6) Lift R-Door up a little to remove it.
5. DISASSSEMBLY AND ASSEMBLY
27
