EXPLODED VIEW AND PARTS LIST
2. TOTAL PARTS LIST
NO PART CODE PART NAME PART DESCRIPTION QUANTITY REMARK
1 3010074800 ASSY CAB URT FR-520NT 1
1 3010074900 ASSY CAB URT FR-550NT 1
2 3012910100 HINGE *T 1
3 3016001230 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
4 3010511700 BOX M/PCB 1
5PCB MAIN AS 1
REFER TO #7
6 7112401211 SCREW TAPPING MFZN, T1 TRS 4X12 3
7CAPACITOR 1
REFER TO #6
8 3011425300 COVER M/PCB BOX 1
9 3012905501 HINGE *M 1
10 3011424700 COVER *M HI 1
11 3016001220 SPECIAL BOLT M 6X20 SWCH22A(WH) 3
12 3018100030 SWITCH DR 1
13 3012103000 FOOT *F *R AS 1
14 3012102900 FOOT *F *L AS 1
15 3016000700 SPECIAL SCREW M6X15 2
16 3012906410 HINGE *U AS 1
17 3016005300 SPECIAL WASR 1
18 3016001230 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
19 3012101500 FOOT ADJ AS 1
20 3012102500 FOOT ADJ *L AS 1
21 7112401211 SCREW TAPPING MFZN, T1 TRS 4X12 2
22 3011439900 COVER CAB BRKT 1
23 3013202700 HOSE DRN B 1
24 3012401400 GRILLE 1
25 7112401211 SCREW TAPPING MFZN, T1 TRS 4X12 6
26 CORD POWER AS 1
REFER TO #9
27 7112401211 SCREW TAPPING MFZN, T1 TRS 4X12 1
28 7001400865 SCREW MACHINE PAN 4X8 BSNI 1
29 3011302900 FUSE GLASS TUBE 1
30 DRYER AS 1
REFER TO #8
31 3014423900 PIPE WICON AS 1
32 3011200500 CLAMP FAN 1
33 3011800400 FAN 1
34 MOTOR C 1
REFER TO #7
35 3012004400 FIXTURE C MOTR 1
36 3010102100 ABSORBER C MOTR 1
37 3011118000 CASE VAPORI 1
ā Caution :
In this Service Manual, some parts can be changed for improving, their performance
without notice in the parts list. So, if you need the latest parts information, please refer
to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr)
