Daewoo MINI Series User Manual

32
6. Part List and Major Specifications
NO PART NAME PART CODE SPEC MAKER REMARK
1
Wash Motor 36189L8000
DWD200BL, DC 310 V, 125 W,
Class F
New Motec
Wash Motor 36189L8500
GJ-2BA003A, DC 310 V, 125 W,
Class F
G&J
Tonlon Motor - - Tonlon
2
Drain Motor 3919601110
BV-DW23, 220-240 V, 2.5 W, Class
E
Gyeong Nam
Nakagawa
Drain Motor 3919601001 SDPV-1, 220 V, 3 W, Class E SAMCO
3 Wash Heater 66127-0001504-00 DHDH-XY600, 230 V, 1400 W Donghai
4
CORD POWER
AS
66112-0004303-00
DTII-3P-07 250V 10A, RVV 3X1.0
CCC CHINA 2.5M WH
Longwell, UNION
Electronics
Power Cord - H05VV-F, 3G×1.5mm² Hongchang
Power Cord - H05VV-F, 3G×1.5mm² Longwell
Power Cord - H05VV-F, 3G×1.5mm² KKDK
Power Cord - H05VV-F, 3G×1.5mm² Seshin
Power Cord - H05VV-F, 3G×1.0mm² HongChang
Power Cord - H05VV-F, 3G×1.0mm² Longwell
Power Cord - H05VV-F, 3G×1.0mm² KKDK
Power Cord - H05VV-F, 3G×1.0mm² Seshin
5
Power Plug - DTⅢ-2P-05, 250 V, 16 A Hongchang
Power Plug - LP-33, 250 V, 16 A Longwell
Power Plug - KKP-4819, 250 V, 16 A KKDK
Power Plug - SEE-72GE, 250 V, 16 A Seshin
6
Fuse (M-PCB) 40504-0002700-00 250 V, 8 A ORISEL MINI 1.5
Fuse (M-PCB) - 250 V, 6.3 A ORISEL MINI 1.5
Fuse (M-PCB) 40504-0002700-00 250 V, 8 A Littel Fuse MINI 1.5
Fuse (M-PCB) - 250 V, 6.3 A Littel Fuse MINI 1.5
7
EMI FILTER 3611913100
EMI FILTER RDFC-2720, MINI
DRUM, 250V 12A,,BRAKET
Ruikai
EMI FILTER - LFT-215W-**, 250 V, 12 A
SangShin
Electronics
8
X-Capacitor 40C01-0014300-00 PCX2 335M, 275 V, 0.1 µF Pilkor MINI 1.0/1.5
X-Capacitor 40C01-0014300-00 CMPP, 275 V, 0.1 µF SUNGHO MINI 1.0/1.5
X-Capacitor - CMPP, 275 V, 0.68 µF SUNGHO MINI 1.0/1.5
X-Capacitor - PCX2 335M, 275 V, 0.68 µF Pilkor MINI 1.0/1.5
9
Relay 40507-0000300-00 GT-1A-12D, 250 V, 25 A GOLDEN MINI 1.5
Relay 40507-0000300-00 SFK-112DM, 250 V, 20 A SANYOU MINI 1.5
Relay 40507-0000300-00 HF160F, 250 V, 25 A HONGFA MINI 1.5
Relay 40507-0000600-00 SMIH-S-112LM, 250 V, 16 A SANYOU MINI 1.5
Relay 40507-0000600-00 OMIH-SH-112LM, 250 V, 16 A TYCO MINI 1.5
Relay 40507-0000600-00 GA-1A-12LH, 250 V, 16 A GOLDEN MINI 1.5
Relay 5SC0101190-00 PCJ-112D3MH, 250V, 3A, TYCO MINI1.0
Relay 5SC0101190-00 Y5-1A-12L, 250V, 3A, GOLDEN MINI1.0
Relay 5SC0101190-00 SRB-S-112DM, 250V, 3A, SANYOU MINI1.0
Relay 5SC0101130-00 GA-1A-12L, 250 V, 10 A GOLDEN MINI1.0
