Daewoo RC-300 Service Manual

5
4-2. CORD REEL ASSEMBLY
1) Take the cord reel out of the body cover.
2) Unscrew the screw and separate the bobbin from the bracket and check the contacts between the Y terminals.
At this time, the bobbin is rotated counterclockwise due to the preserved winding.
3) If the reel spring is broken, unscrew the 2 screws and replace it.
4) Unscrew the screw and part bobbin.
5) Check the connections between the power cord and the terminals.
6) When assembling, make the reserved winding 4 revolutions of bobbin clockwise.
CAUTION - WHEN DISASSEMBLING, THE REEL SPRING MAY SPRING OUT OF THE COVER.

Daewoo RC-300 Specifications

General

Brand	Daewoo
Model	RC-300
Category	Vacuum Cleaner
Language	English
