Daewoo RC-300 Service Manual

6
5. EXPLODED VIEW AND PARTS LIST
5-1. BODY ASSEMBLY
NO PART NAME PART CODE SPEC. Q TY
1 BODY 3620406300 PP 1
2 ROLLER BACK 3624703400 PP 2
3 ROLLER FRONT 3624703600 PP 1
4 SHAFT ROLLER 3624901000 SWRM 1
5 BRACKET ROLLER 3620601500 PP 1
6 HOLDER FILTER 3623004000 PP 1
7 SPRING HOLDER 3625106000 SK-5 1
8 GASKET 3624004800 RUBBER FOAM 1
9 FILTER-IN 3621904200 POLYESTER 1
10 BAG FILTER 3620202500 “2-LAYER, 3L” 1
11 SCREW TAPPING 7128401212 T2S WAS 4X12 1
