Daewoo RC-300 Service Manual

7
5-2. BODY COVER ASSEMBLY
NO PART NAME PART CODE SPEC. Q TY
1 COVER BODY 3621416900 PP 1
2 LEVER CR 3623702000 PC LEXAN 121 1
3 SPRING LEVER 3625104300 HSW3 1
4 FRAME STOPPER 4565A35070 POLY ACETAL 1
5 STOPPER CR 4569C35082 NBR 1
6 SWITCH PUSH 3629002000 “7A/250V, (SKT)” 1
7 HARNESS 3622710000 RECEP+WIRE (BK) 1
8 HARNESS
3622709600 RECEP+WIRE (WH), VDE 1
3622709610 RECEP+WIRE (WH), GENERAL 1
9 MOTOR UNIVERSAL 3962511410 230V 1100W DMI 1
10 MOUNT MOTOR 3627900900 TPE 1
11 PACKING MOTOR 3624004900 SBR 1
12 SCREW TAPPING 7171402011 TT2 PAN 4X20 4
13 CASE FILTER 3621103000 PP 1
14 FILTER EXHAUST 3621904300 POLYESTER 1
